1) Integrate functions of main drive motor controller, oil‑pump DC/AC, air‑pump DC/AC, DC/DC, heating, air‑conditioning, defrosting, superstructure and fuel‑cell power distribution;
2) Mature parallel technology for main‑drive IGBTs with current sharing degree ＜3%;
3) Maximum operating voltage of 800V;
4) Single‑chip multi‑core centralized control, high integration level, over 10% lighter than similar products from competitors;
5) DC/DC supports 3.0;
6) Key components including IGBTs and current sensors are domestically produced with reliable supply chain.
1) Integrate functions of main drive motor controller, oil‑pump DC/AC, air‑pump DC/AC, DC/DC, heating, air‑conditioning, defrosting, superstructure and fuel‑cell power distribution;
2) Mature parallel technology for main‑drive IGBTs with current sharing degree ＜3%;
3) Maximum operating voltage of 800V;
4) Single‑chip multi‑core centralized control, high integration level, over 10% lighter than similar products from competitors;
5) DC/DC supports 3.0;
6) Key components including IGBTs and current sensors are domestically produced with reliable supply chain.
Product Parameters
General Parameters | |
Rated Voltage | 610VDC |
Weight | ≤20kg |
Water flow rate and temperature | 20L/min/≤65℃ |
Operating ambient temperature | -40℃～85℃ |
Waterproof rating | IP67 |
MCU | |
Voltage range | 400VDC～800VDC |
Rated/Peak Capacity | 140kVA/280kVA |
Rated/Peak current | 200A/400A |
Efficiency | ≥98%(rated operating condition) |
DCAC | |
Rated/Peak Capacity | 7.5/15kW |
Rated/peak current | 19/30A |
DCDC | |
Rated output voltage | 27.5±0.5VDC |
Rated Output Power | 3kW |
Power distribution | |
Electric air‑conditioner | 6kW |
Electric heating | 6kW |
Electric defrosting | 6kW |
